2.8 Inch 240*320 LCD Display Module SPI Serial Module TFT Color Screen Driver IC ILI9341
- Hassle-Free Warranty
- 30-Day Money-Back Guarantee
- Fast, Free Shipping
- Lifetime Customer Support
Description
Product Features
Size: 2.8 inches
Driver chip: ILI9341
Font chip: GT30L32S4W
Resolution: 240 * 320
Display area: 43.2 x 57.6 (mm)
Physical size: 51 * 81.2 (mm)
Interface type: SPI interface
Number of pins: 8Pin
Display color: full color
Pixel size: 0.18x0.18 (mm)
Working temperature: -20 ~ 70 degrees
Working voltage: 3.3V
Interface description:
| PIN No. | Symbol | Description |
| GND | Ground | |
| VCC | Power supply for LCD (3.3V) | |
| CLK | This pin is used serial interface clock in 4-wire 8-bit serial data interface. | |
| MOSI | Serial input signal. The data is applied on the rising edge of the SCL signal. | |
| RES | LCM Reset pin Signal is active low. | |
| DC | Data Command Control. This pin is Data Command ccaitrd pin. When the pin is pulled high, the input at D7-D0 is treated as display data. When the pin is pulled low, the input at D7 ~D0 will be transferred to the ccmmand register | |
| BLK | BLK is a backlight control pin, which can be left unconnected by default; BLK should be connected to low level when the backlight is turned off. | |
| MISO | Font output / LCD data output (for reading internal screen data) | |
| CS1 | LCD screen chip selection | |
| 10 | CS2 | Font chip chip selection |
Package includes:
1 x LCD module
2.8 Inch 240*320 LCD Display Module SPI Serial Module TFT Color Screen Driver IC ILI9341
$20.99
